The S4(T) Series Ultra-Precision Transmitter is the pinnacle of the S-series product line, offering an industry-leading Accuracy Class of 0.1. Engineered for the most demanding applications where precision is the primary requirement, the S4(T) serves as a gold standard for electrical parameter conversion.
Featuring state-of-the-art Hybrid Thick-Film Technology and ultra-linear sensing components, this transmitter provides unparalleled measurement integrity for AC/DC voltage, current, power, and frequency. It is the ultimate choice for scientific research, high-end power quality analysis, and precision-critical industrial automation.
Ultimate 0.1 Class Accuracy
●: The highest precision level in the series, ensuring laboratory-grade data reliability.
Maximum Isolation (2500V DC)
●: Enhanced safety and signal integrity with full isolation between input, output, and auxiliary power.
Low Temperature Drift
●: Advanced circuit design maintains consistent performance even under varying ambient temperatures.
Elite Hybrid Thick-Film Circuitry
●: Delivers long-term stability and high resistance to industrial interference.
Fast & Stable Response
●: Response time ≤ 400ms for real-time monitoring of critical electrical loads.
Robust & Flame Retardant
●: Housed in high-strength flame-retardant plastic with safety terminal protection.
Flexible Installation
●: Compatible with standard
35mm DIN Rail
or screw mounting.
Parameter | Specification |
Accuracy Class | 0.1 Class (Laboratory Grade) |
Input Parameters | AC/DC Current (A), AC/DC Voltage (V), Power (W/Var), Hz, Phase |
Output Signals | DC 4-20mA, 0-20mA, 0-10V, 0-5V, 2-10V, etc. |
Isolation Voltage | DC 2500V(Input / Output / Power) |
Response Time | ≤ 400ms (High-stability) |
Temperature Coefficient | ≤ 50-100ppm/℃ (Ultra-stable) |
Overload Capacity | 2x Rated (Continuous); 10x Rated / 1s (Current) |
Housing Material | High-strength Flame Retardant Plastic |
Mounting Type | 35mm DIN Rail or Screw Mounting |
Designed to fit standard industrial cabinets while maintaining high isolation distances:
Single Parameter (Current/Voltage)
●: 120 × 50 × 80 mm (L × W × H)
Multi-Parameter (Power/Combined)
●: 120 × 110 × 80 mm (L × W × H)
Scientific Research & Laboratories
●: Precise signal conditioning for experimental data acquisition.
High-End Power Quality Analysis
●: Monitoring micro-fluctuations in precision power grids.
Critical Industrial Control
●: Feedback loops for high-performance drives and chemical reactors.
Defense & Aerospace
●: Reliable and accurate signal conversion in demanding environments.
Advanced Energy Audit
●: The most accurate data source for carbon footprint and energy efficiency modeling.
Feature | S4(T) Series (Premium) | S3(T) Series (Standard-Plus) | N3 Series (Standard) |
Accuracy | 0.1 Class | 0.2 Class | 0.5 Class |
Target | Lab / Research / Top-tier | Utility / Professional | General Industrial |
Isolation | DC 2500V | AC 2000V | AC 2000V |
Stability | Maximum | High | Standard |
To ensure the best configuration for your high-precision needs, please specify:
Input Variable
1. : (e.g., AC 0-500V, AC 0-5A, Frequency 45-55Hz)
Output Signal
2. : (e.g., 4-20mA DC, 0-10V DC)
Power Supply
3. : (e.g., AC/DC 85-265V Wide Range or DC 24V)
Application Environment
4. : (e.g., Temperature-controlled lab or outdoor cabinet)
S4(T) Series: Redefining Precision in Signal Conversion. When your system demands the absolute highest accuracy available, the S4(T) series provides the verified, laboratory-grade performance required for mission-critical applications.
